Technical Specifications:
Nominal Cooling Capacity: | 8KW |
Input Power: | 3.6KW+6KW |
Power Voltage: | 3Phase-400V-50Hz |
Chilled Fluid Type: | Fresh water |
Temperature Control Range: | 5℃ to 80℃ |
Temperature Control Accuracy: | ±1 K |
Compressor Type: | Panasonic – Hermetic scroll |
Compressor Motor: | 4.1KW |
Quantity of Compressor: | 1 |
Refrigerant Type: | R407c |
Refrigerant Control Method: | Thermal expansion valve |
Quantity of Refrigerant Circuit: | 1 |
Condenser Type: | Air Cooled Type – Aluminum fin with copper tube |
Fan Power*Qty.: | 0.22KW |
Evaporator Type: | Immersion SUS304 coil |
Pump Type: | SUS304 centrifugal type |
Pump Motor: | 0.75KW |
Pump Max Flow: | 7m³/h |
Pump Max Head: | 28meters |
Connection Type: | Male thread |
Chilled Water Inlet Diameter: | 1″ |
Chilled Water Outlet Diameter: | 1″ |
Chilled Water By-pass Valve: | Included |
Appearance: | Packaged type with grayish white painting |
Dimension: | 960mm*530mm*1175mm |
Net Weight: | 135kgs |
