Technical Specifications:
| Nominal Cooling Capacity: | 10TON |
| Power Voltage: | 3Phase/380-415V/50Hz |
| Chilled Fluid Type: | Fresh water |
| Temperature Control Range: | 5℃ to 30℃ |
| Controller Type: | Micro-processor |
| Temperature Control Accuracy: | ±1 K |
| Compressor Type: | Panasonic – Hermetic scroll |
| Compressor Motor: | 4.4KW*2 |
| Quantity of Compressor: | 2 |
| Refrigerant Type: | R410a |
| Refrigerant Control Method: | Thermal expansion valve |
| Quantity of Refrigerant Circuit: | 2 |
| Condenser Type: | Shell and tube |
| Condenser Connection Size: | 1-1/2″ |
| Evaporator Type: | Immersion SUS304 coil |
| Pump Type: | SUS304 centrifugal type |
| Pump Motor: | 1.5KW |
| Pump Max Flow: | 11m³/h |
| Pump Max Head: | 35meters |
| Connection Type: | Male thread |
| Chilled Water Outlet Diameter: | 1-1/2″ |
| Chilled Water By-pass Valve: | Included |
| Appearance: | Packaged type with grayish white painting |
| Dimension: | 1180mm* |
