Technical Specifications:
| Nominal Cooling Capacity: | 183.8KW / 52.3TR |
| Input Power: | 65.8KW |
| Chilled Fluid Type: | Fresh water |
| Temperature Control Range: | -5℃ to 25℃ |
| Controller Type: | Siemen PLC |
| Temperature Control Accuracy: | ±1 K |
| Compressor Type: | Hanbell – Semi-hermetic Screw |
| Compressor Motor: | 53.1KW |
| Quantity of Compressor: | 1 |
| Refrigerant Type: | R134a |
| Refrigerant Control Method: | Thermal expansion valve |
| Quantity of Refrigerant Circuit: | 1 |
| Condenser Type: | Air Cooled Type – Aluminum fin with copper tube |
| Evaporator Type: | Shell and tube |
| Chilled Water Outlet Diameter: | DN100 |
| Appearance: | Packaged type with grayish white painting |
| Dimension: | 3600mm*1800mm*2290mm |
| Net Weight: | 2850kgs |
