The instrument features automatic electrolysis current regulation, intelligent endpoint recognition, and blank current compensation, delivering consistent and dependable results under varying laboratory conditions. Equipped with an 8-inch IPS color touchscreen, a built-in thermal printer, and RS-232C / WiFi connectivity providing an efficient and user-friendly solution for petroleum, power, chemical, pharmaceutical, and research testing facilities.
Test Standards of TT- MT3100 Karl Fischer Moisture Titrator
ASTM D6304 / ASTM D1533
Application of TT- MT3100 Karl Fischer Moisture Titrator
Widely used for user-friendly solution for petroleum, power, chemical, pharmaceutical, and research testing facilities.
Field of application
- Petroleum refineries and petrochemical production processes
- Lubricating oil, hydraulic oil, and transformer oil moisture analysis
- Turbine oil and base oil quality control
- Diesel, gasoline, aviation fuel, and biodiesel moisture determination
- Organic solvent and chemical raw material inspection
- Power industry insulating oil testing and equipment maintenance laboratories
- Pharmaceutical raw material testing and production control
- University and scientific research institute laboratories
- Third-party inspection and certification laboratories
Features of TT- MT3100 Karl Fischer Moisture Titrator
- Integrated coulometric titration structure featuring a compact and streamlined dual-unit design.
- Wide measurement range (3 μg–100 mg) with rapid analysis speed and low reagent consumption.
- Automatic adjustment of electrolysis current with intelligent endpoint identification; includes temperature and blank current compensation.
- 8-inch IPS capacitive touchscreen with high brightness and adjustable backlight, combined with auto-balance function and user-friendly interface for easy operation.
- Real-time monitoring of electrolysis current and blank current throughout the testing process for complete visibility.
- RS-232C and WiFi connectivity allowing transfer of moisture data, measurement values, and calibration curves to a PC.
- Supports bulk injection and gravimetric sample introduction; automatically calculates moisture content and displays in both μg and ppm units simultaneously.
- Measuring electrode signal shown as a progress indicator on the touchscreen, directly reflecting electrolyte moisture status.
- Ample data storage ensures test results and calibration parameters can be conveniently accessed at any time.
- Automatic detection of electrode open-circuit and short-circuit conditions with electrolyte limit protection for safe and stable operation.
- Built-in real-time clock displaying date and time (year/month/day/hour/minute/second) with automatic timestamp recording of historical data.
Technical Specifications of TT- MT3100 Karl Fischer Moisture Titrator
| Model | TT- MT3100 |
| Test Method | Coulometric Karl Fischer Titration |
| Measuring Range | 3 μg – 100 mg |
| Detection Limit | 3 μg |
| Analysis Time | Max. 2.4 mg/min (electrolysis speed) |
| Accuracy | 10 μg–1 mg H2O: ±3 μg; >1 mg H2O: ±3% |
| Resolution | 0.01 μg |
| Endpoint Indication | Display / Buzzer / Indicator Light |
| Calibration Curves | Up to 10 stored curves |
| Printer | 16-character dot matrix thermal printer |
| Display Units | μg Water / ppm (simultaneous) |
| Display | 8-inch IPS capacitive touchscreen |
| Data Output | Built-in printer / RS-232C / WIFI |
| Power Supply | AC 220V ±10%, 50 Hz |
| Rated Power | 10 W |
| Operating Temperature | 10°C – 35°C |
| Relative Humidity | ≤ 80% |
| Instrument Weight | Main unit: approx. 5 kg |
| Dimensions | Main unit: 320 × 260 × 150 mm ; Titration unit: 250 × 102 × 90 mm |
