TT-C9802 Gas Chromatography Standard:
QBT 2929,GB/T 10004-2008, YBB 00132002
TT-C9802 Gas Chromatography Features:
- Economical and practical, excellent performance and quality.
- Adjustable gas circuit pressure, stable flow, with multiple gas circuit system of nitrogen, hydrogen, air, exhaust, shunt, cleaning.
- LCD screen displays temperature in real time.
- Cellular overall structure design, convenient to install and maintenance.
- Advanced noise resistant system work quietly.
- Over-temperature protection function, with program protection and circuit protection double insurance.
- With data workstation, professional software support and powerful data analysis function.
- Display working condition and chromatogram curves; curves can be zoomed and moved.
- Professional test report can export PDF file.
- Manual button switch, its function is equal to “start collecting”, which is convenient for sampling.
- Easy to operate detector and baseline calibration.
TT-C9802 Gas Chromatography Specifications:
| Item | Technical Parameters |
|---|---|
| Detector | hydrogen flame detector (FID）（optional for others） |
| Detector Parameters | Sensitivity Mt≤1×10-11g/s（ n−hexadecane）；baseline drift≤0.02mv/h；noise≤0.02mv |
| Chromatographic column | OV-1701 capillary-column chromatography，50m*0.32mm*0.5um，maximum service temperature:400℃（optional for other chromatographic column） |
| Injection port | Capillary column injection port(optional for packed column injection port) |
| Column oven size | 240×210×240mm |
| Temperature range | Highest 400℃ |
| Temperature | 0.1% |
| Temperature resolution | 0.1℃ |
| Heating rate | 0~40℃/minute |
| Carrier gas source | N2，purity 99.99%，0.4MPa，dry |
| Hydrogen gas source | Purity 99.99%，0.4MPa，dry |
| Air source | 0.4MPa，dry，clean，oil-free |
| Air connection | Φ3mm gas pipe |
| Instrument size | 500×550×500 mm |
