TT- IVS200 ViscoPlus Intrinsic Viscosity (IV) tester is an advanced test instrument designed for fast and safe intrinsic viscosity tester. It is designed according to ISO, ASTM, DIN and GB test standards. Our system can directly measure the intrinsic viscosity.
Test Standards:
ASTM D4603, ISO 1628, DIN 53728, GB/T 17931, GB/T 14190
Features:
- Automatic Sample feeding: Minimize contact with chemical
reagents to enhance safety and significantly reduce labor
intensity - Automatic Washing: Our automatic washing process
makes the equipment completely automated and no contact
with chemicals - No need to disassemble the capillary viscometer: Reduce the damage to the capillary viscometer and scaling down the frequency of water changes in the water bath, which may result from a broken capillary viscometer.
- Continuous measurement: Adding the dissolved sample solution, it can test
- Multi-functional parameters
A. It can complete the testing of kinematic viscosity, dynamic viscosity, relative viscosity, specific viscosity, viscosity number, intrinsic viscosity, viscosity average molecular weight and so on. All the viscosity calculation formulas are built in our software and very convenient for our users.
B. The serial extrapolation method can be completed easily, and the parallel extrapolation method can be completed by TT- IVS200 ViscoPlus.
C. The data statistics function can be used to analyze the change trend of the sample and provide the basis for controlling the quality of the product.
D. Double field constant temperature will save the constant temperature time and improve the testing efficiency.
Technical Parameters:
| Measuring range | 0.35~100000 mm2/s (Mpa.s) |
| Thermostatic medium | Water |
| Volume of bath | 8L |
| Temp accuracy | Better than ±0.01 |
| Time range | 0~9999.999 s |
| Timing accuracy | 0.001s |
| Temp range | 15-65 0C |
| Temp fluctuation and uniformity | ±0.01 0C |
| Measure position | 2 positions |
| Heating power | 1kw |
| Applicable materials | PET, PBT, PA, PLA, PBAT, PGA, PS, SAN, PBT, PMMA, PCT, PA, PIB, TPU, PAM, PSU, PEN, PC, PLA, CA, PVC, SB, Chitin, PAN,TP and etc. |
| Size | 720*320*700 mm |
| Cooling system | 200*360*380 mm |
| Control box | Built in |
| Sample feeding | Auto |
| Testing | Auto |
| Calculate result | Auto |
| Wash tubes | Auto |
| Dealing samples | 12 samples |
| Software | Yes |
| Upgrade | 1 position to match 6 sample bottles, upgrade to 9 bottles |
