Multifunctional Tensile Tester Standard:
ASTM E4, ASTM F88, ASTM D1938, ISO 37, GB 19083-2010, YY0469-2011, GB 2626-2006, YY/T0969-2013, YY/T0681.13-2014, GB/T32610-2016
Multifunctional Tensile Tester Specifications:
| Item | Technical parameters |
| Test force range | 0~500N (0~1500N optional ), 1400% elongation |
| Test accuracy | Within ±0.5% of the displayed value (grade 0.5) |
| Test speed | 1-500mm/min (infinitely variable speeds) |
| Displacement | Within ±0.5% of the displayed value |
| Test width range | 30mm (50mm can be customized) |
| Travel distance range | 750mm |
| Instrument size | 460mm×525mm×1430mm |
| Power | 1000W |
| Power supply | AC 220V 50Hz |
| Weight | 86kg |
Multifunctional Tensile Tester Configuration:
| A、Spare parts | ||||
| NO. | Name | Remark | Quantity | |
| 1 | Power cable | 3*0.75 10A 1.8M | 1 PC | |
| 2 | Communication cable | RS232 nine-pin data cable | 1 PC | |
| 3 | Tensile clip | 30mm | 1 PC | |
| 4 | Piercing clip | 1 PC | ||
| 5 | Software flash disk | 4G | 1 PC | |
| 6 | Buckboard | 1 Set | ||
| 7 | Allen wrench | 1 Set | ||
| 8 | Right-angle tear blade | 1 Set | ||
| 9 | Wooden box | 1 PC | ||
| 10 | Cross screwdriver | 6-10mm | 1 PC | |
| B、Optional parts | ||||
| NO. | Name | Unit | Quantity | Remark |
| 1 | Computer (win7 32bit) | set | 1 | Optional |
| 2 | Pneumatic clip | set | 1 | Optional |
| 3 | Metrology Certificates | Optional | ||
| C、User provide | ||||
| 1 | Power supply 500w 220V 10A three holes socket ground wire | |||
| 2 | 1 set of computer（with nine-pin COM port），Windows7 | |||
Multifunctional Tensile Tester Features:
- Flexible and various interfaces and control methods, which can be used for multiple tests such as stretching, peeling, heat sealing, tearing, puncture, compression, bending, shearing, etc., setting off multiple parameters such as speed, thickness, and pinch.
- High measurement accuracy, the test measurement accuracy can reach 0.5 grade.
- The whole process is controlled by a computer, and the test is displayed online after the test. It can automatically perform data storage, data analysis, and comparison functions, curve overlay recording function, an online printing function, arbitrary zoom function.
- The full digital control system cooperates with the imported AC servo system and motor to control the zero displacements.
- High-precision ball screw loading, stable loading, long testing machine life, long-term stability, and energy saving.
- Load/deformation measurement: With multiple sub-channels, it supports extended measurement of multiple sensors.
- Wide speed range, suitable for high and low-speed tests.
- The open data structure, whether it is result parameters or process data, allows users to call randomly, users are very convenient. Self-editing report function, the data can be easily imported into an Excel table for easy post-processing.
- The control and measurement unit can choose the built-in type (simple appearance, save space) and external type (easy to upgrade, maintain and operate separately from the computer).
- Have perfect limit protection, overload protection, emergency stop, and other safety protection functions. Make the test run safe and reliable.
- A high sampling rate (100 times/second), make the test data more accurate.
- The core uses imported parts, which is more accurate and more durable
- Double-column table structure, beautiful and elegant, good rigidity.
- Optional pneumatic fixture, suitable for a variety of fixtures.
