TT-AVS100 Micro Separometer

TESTRON TT‑AVS100 Micro Separometer is designed to evaluate the water separation characteristics of aviation turbine fuels in accordance with ASTM D3948. The instrument operates by forming a controlled water–fuel emulsion using a high‑speed mixer within a syringe. This emulsion is then discharged at a programmed flow rate through a standardized fiberglass coalescer. The separated fuel is subsequently analyzed using a light transmission measurement system to determine the presence of uncoalesced water.

Test Standard of TT-AVS100 Micro Separometer

ASTM D3948

Application of TT-AVS100 Micro Separometer

Used to ensure aviation fuel is clean, free from contaminants, and capable of properly separating water, which is essential for flight safety and fuel system protection.

Features of TT-AVS100 Micro Separometer

Rapid and automatic determination of water separation characteristics
Supports multiple testing standards selectable via system settings
User-friendly operation with automatic timing and intuitive interface
Real-time visual display of test progress on the screen
Enables storage of test results with access to historical data records
Modular design allows independent maintenance and operation of key components
Equipped with fault alarm system and automatic protection for critical components
Automatic battery voltage monitoring with integrated auto-charging function

Technical Specifications of TT-AVS100 Micro Separometer

Model	TT-AVS100
Measuring range	50~100, Resolution: 1
Detection cycle	5~10min
Power supply	Battery powered and compatible with AC and DC power supply AC: 220V±10%, 50Hz±5% DC: Built-in battery can support 25 tests independently
Stirrer revolving speed	25000±1000rpm
Sample temperature	18~29℃
Structure	Portable box
Dimension	470380170mm
Weight	≤ 20kg
Maximum power dissipation	≤200V
