Application of TT-2DE Metallographic Sample Grinding and Polishing Machine
These machines are designed to handle various materials, including metals, alloys, and composites, ensuring consistent and high-quality sample preparation.
Features of TT-2DE Metallographic Sample Grinding and Polishing Machine
- This machine is equipped with a water-cooling device, which can cool the sample during grinding and polishing and prevent damage to the metallographic structure due to overheating.
- This machine has a dual-disc and dual-control structure. The two grinding and polishing discs are separately controlled through frequency converter speed regulation.
Technical Specification of TT-2DE Metallographic Sample Grinding and Polishing Machine
| Items | Technical Parameters | Optional Accessories |
| Structure | Dual disk and dual control | Ø Magnetic disk φ200mm, φ230mm or φ250mm Ø Anti-stick disk φ200mm, φ230mm or φ250mm Ø Sandpaper 320#, 600#, 800#, 1200# Ø Polishing cloth Silk velvet, canvas, woolen cloth Ø Diamond polishing agent W0.5um, W1um, W2.5um |
| Grinding and polishing disk diameter | φ203mm | |
| φ230mm or φ250mm (optional) | ||
| Disk speed | 50-1000r/min (stepless) | |
| 300r/mi, 600r/min (fixed speed) | ||
| Sandpaper diameter | φ200mm | |
| Motor | YSS6324, 550W | |
| Power supply | 220V 50HZ | |
| Dimensions | 700*600*278 (mm) | |
| Net weight | 57kg | |
| Gross weight | 66kg |
Standard Delivery of TT-2DE Metallographic Sample Grinding and Polishing Machine
- Main unit
- Polishing cloth
- Sandpaper
- Grinding disk
- Polishing disk
- Water inlet pipe
- Water outlet pipe
- User Manual
