TT-VS5/10/30/50 Series Practical Digital Vickers Hardness Tester Description:
- Half automatic and intelligent Vickers hardness testing machine of a new and high-tech product combining the optical, mechanical and electronic techniques.
- It adopts the close-loop force sensor to replace the traditional quality weight, this innovative design makes the instrument more accurate and stable.
- Selection of testing force and dwell time is controlled and monitored on the front panel, it is automatic during the process of loading, dwell and unloading.
- It adopts digital microscopes with adjustable LED illuminator, doesn’t the operator to read the detail length of indentation, it only needs the operator to aim the D1, D2 diameter of indentation and press the length key twice, then the built-in computer can compute the Vickers scale and display the final testing result on LCD display automatically.
- It doesn’t need the operator to read the diagonal of indentation and check the Vickers testing table, it improves the speed and accuracy of hardness testing obviously.
- It can be equipped with CCD indentation automatically measuring device or video measuring device.
- It is suitable for the testing Vickers hardness value of the micro and thin pieces, the parts with the strengthening layer, heat treating and permeated and coated plane surface, the crisp materials such as the agate, glass, ceramics.
- An ideal hardness measuring instrument for the scientific research institutes, the universities, the industrial production units and the metallographic institutes.
TT-VS5/10/30/50 Series Practical Digital Vickers Hardness Tester Specifications:
| Product Name | Digital Vicker Hardness Tester | |||||
| Model | TT-VS 5M/5A | TT-VS 10M/10A | TT-VS 30M/30A | TT-VS 50M/50A | ||
| Testing Force | Kgf | 0.3,0.5,1,2,2.5,3,5 | 0.3,0.5,1,2,2.5,3,5,10 | 0.5,1,2,2.5,3,5,10,20,30, | 1,2,2.5,3,5,10,20,30,50 | |
| N | 2.94,4.9,9.8,19.6,24.5,29.4,49.0 | 2.94,4.9,9.8,19.6,24.5,29.4,49.0,98, | 4.9,9.8,19.6,24.5,29.4,49.0,98,196,294 | 9.8,19.6,24.5,29.4,49.0,98,196,294,490 | ||
| Testing Range | 8HV0.3~2900HV5 | 8HV0.3~2900HV10 | 8HV0.5~2900HV30 | 8HV1~2900HV50 | ||
| Lens & Indenter Switch | Manual-turret(HVS-5M/10M/30M/50M) , Auto-turret(HVS-5A/10A/30A/50A) | |||||
| Loading Control | Automatic( Loading, Dwell and Unloading) | |||||
| Data Output | RS232/Mini-printer | |||||
| Microscope Magnification | TT-VS-5M/5A | Observation:20x, Measurement:40x | ||||
| TT-VS-10M/10A | Observation:10x, Measurement:40x | |||||
| TT-VS-30M/30A/50M/50A | Observation:10x, Measurement:20x | |||||
| Eyepiece | 10x | |||||
| Dwell Time | 0~60s (5 seconds as a unit) | |||||
| Hardness Indication | LCD Display | |||||
| Illumination | Halogen light-source | |||||
| Max Test Height | 170mm | |||||
| Test Throat | 130mm | |||||
| Power Supply | AC220V/50Hz;110V/60Hz | |||||
| Dimensions | 530×280×630 mm | |||||
| Packing Dimensions | 630x460x710 | |||||
| Gross/Net Weight | 50/35kg | |||||
| Execution Standard | GB/T4340.2, EN-ISO6507, ASTME10-08, ASTME-384 | |||||
TT-VS5/10/30/50 Series Practical Digital Vickers Hardness Tester Packing list:
| Packing List | Packing List | Packing List | Packing List |
| Mainframe | 10x Eyepiece | Accessories Box | Instruction Manual |
| Vickers Indenter | Level Screw | Mini-printer(P/Z type) | Anti-dust Cover |
| Vickers Blocks | Gradienter | Power Cable | Halogen Lamp |
| 10X Objective | Fuses | V-shape Test Anvil(HV-30/50/) | |
| 20x Objective | Screwdriver | Big Test Anvil(HV-30/50) | |
| 40x Objective | Allen Wrench | X-Y Test Anvil(HV-5/10) | |
TT-VS5/10/30/50 Series Practical Digital Vickers Hardness Tester Optional Accessories:
| Optional Items | Optional Items | Optional Items |
| CCD Measuring System | Filament Clamp | LCD Monitor |
| Vickers Measuring Software with Capture card and Dongle | Flat Clamp | Mediuu-Flat Anvil |
| Thin-piece Clamp | Hardness Blocks | |
| Metallurgical Specimen Cutter | Metallurgical Specimen Polisher | Metallurgical Specimen Mounting Press |
