Features of TT-RC1100 Rebar Corrosion Detector
- Determine the degree of corrosion of steel bar by non-destructive method
- The degree of corrosion can be indicated by gray scale of 9 grades
- Transmits measurement data to computer for further analysis through serial port or USB port
- The software has simple interface, easy to operate and can create test report directly
Technical Specifications of TT-RC1100 Rebar Corrosion Detector
| Model | TT-RC1100 |
| Measurement range | ±1100mV |
| Accuracy | ±1mV |
| Distance of measuring point | 1-100cm |
| Measurement area | 8100m² |
| Probe | ⌀30mm x 180mm, 100g |
| Resolution of LCD | 160 x 128 |
| Data storage | Data to 5400 pieces of measurement zone 1100 pieces of measurement points |
| Power supply | No.5 LR6 (Alkaline) batteries – 6pcs |
| Dimension | 21×15.3x9cm, 880g |
| Working Environment | Ambient temperature: 0ºC ~ + 40ºC Keep away from direct sunshine and any electromagnetic interferences |
