Application of TT-PAF100 Plastic Ash Furnace
It is ideal for use in plastic processing industries, research laboratories, quality control departments, and academic institutions. It ensures accurate and reliable measurement of inorganic content, supporting material evaluation and compliance testing.
Features of TT-PAF100 Plastic Ash Furnace
- Adopts advanced domestic technology and integrate the control box with the furnace body into a single, compact unit eliminating the need for complex installation and offering a streamlined, modern appearance.
- Outer shell is constructed from high-quality steel plates, formed by precision folding and welding, ensuring strength and durability. The inner chamber is a rectangular, one-piece lining made of high-alumina and silicon carbide refractory materials, providing excellent thermal resistance and structural stability.
- A spiral heating element made from iron-nickel-chromium-aluminum alloy wire is uniformly distributed through wire grooves positioned at the top, bottom, and both side walls of the chamber. This design enables even multi-directional heating—up, down, left, and right—for consistent temperature distribution.
- Features a fully sealed structure with a high-efficiency thermal insulation layer composed of refractory fiber aluminum silicate cotton and diatomite insulation products placed between the chamber and the outer shell. This ensures minimal heat loss and enhanced energy efficiency.
Temperature Control of TT-PAF100 Plastic Ash Furnace
- Adopts the overall design and humanized menu design, uses industrial PID self-tuning control technology, dual-screen high brightness wide window digital display. The display value is clear and intuitive.
- The microcomputer intelligent control has solved the disadvantages of temperature overshoot and so on, and the temperature control effect is excellent. After setting the temperature, the instrument automatically controls the heating output, and the temperature control is precise and stable. Overtemperature alarm and automatically cut off heating output. It has the function of starting the timer or starting the timer when the temperature is set.
Technical Specifications of TT-PAF100 Plastic Ash Furnace
| Model | TT-PAF100 Plastic Ash Furnace |
| Temperature range | 100 ~ 1000℃ |
| Volatility | ±2℃ |
| Display precision | 1℃ |
| Furnace size | 200*120*80 mm |
| Shape size | 580*420*660mm |
| Heating rate | ＞10℃/min |
| Power | 2.5KW 220V, 50Hz |
| Temperature Control System of TT-PAF100 Plastic Ash Furnace | |
| Temperature measurement | K dividing nickel chromium nickel silicon thermocouple |
| Control system | PID adjustment, display precision1℃; |
| Complete set of electrical appliances | Adopt brand contactor, cooling fan, solid state relay |
| Time system | It can set working hours, arrive at constant temperature time, and stop automatically |
| Overtemperature protection | Built in two stage overtemperature protection device, double insurance. Over temperature alarm, over temperature cut-off; |
| Operation mode | The whole range can be adjusted at constant temperature and run at constant temperature.
|
Furnace structure and materials
- Shell material
The outer case is made of high-quality cold plate and treated with phosphoric acid film salt
- Furnace gallbladder material
Using high aluminum inner liner, good wear resistance, high temperature furnace heating up and down
- Heat insulation method
Insulating bricks and thermal insulation cotton
- Thermometer
The thermocouple enters from the top of the furnace body
- Terminal
The heating furnace wire post is positioned behind the furnace body
- Controller
Located at the bottom of the furnace body, a control system is installed, and the compensating conductor relates to the furnace body
- Heating element
High temperature resistance wire
- Weight：60KG
- Standard packing: wooden case
