Application of TT-OFT500 Optical Cable Tensile Testing Machine (Indoor)
This equipment is used to test the tensile performance of butterfly drop optical cables in access networks. It measures optical fiber attenuation and strain under specified tensile loads to ensure the cable meets installation and performance requirements.
Features of TT-OFT500 Optical Cable Tensile Testing Machine (Indoor)
- Computer-controlled system
- Servo motor drive
- Precision ball screw for load application
- High-precision load sensor for accurate signal measurement
- Stable loading performance
- Accurate and reliable measurement
- Fast control response
- Multiple control methods available
- Convenient and precise digital calibration of load and elongation
- Full load protection and position protection
Technical Specifications of TT-OFT500 Optical Cable Tensile Testing Machine (Indoor)
| Model | TT-OFT500 |
| Max Test Force | 2kN, 500N |
| Force measurement range | (1%～100%) F.S. |
| Force resolution | ±250000 yards, the whole process is not divided, the resolution is unchanged |
| Accuracy of force indication | ±0.5% |
| Force holding time | not less than 3 hours, can be set arbitrarily |
| Relative error of the load protection | ±0.5% |
| Deformation measurement range | (0~50) mm |
| Deformation resolution | 0.001mm |
