Application of TT-IMM150 Benchtop Injection Molding Machine
It is widely used in the mass production of plastic components across various industries. They are essential in manufacturing automotive parts, medical devices, consumer electronics, packaging products, and more.
Features of TT-IMM150 Benchtop Injection Molding Machine
- Ergonomically designed worktable height to ensures easy operation and improves work efficiency.
- Movable components of the template and machine column, used high‑rigidity copper bushings, ensuring smooth movement, high precision, and long service life.
- Mold installation and dismantling are simple and convenient, reducing setup time.
Technical Specifications of TT-IMM150 Benchtop Injection Molding Machine
| Model | TT-IMM150 |
| Clamping force | 5t |
| Clamping mode | servo motor positioning + leak screw locking |
| Max. temperature | 380℃ |
| Positioning precision | 0.02mm |
| Screw size | 20x500mm |
| Injection speed | 150mm/s |
| Injection pressure | 70Mpa |
| Max. mold size | 130x150x (120-170)mm |
| Sample mass | 15g |
| Dimension | 1300*500*410mm |
| Weight | 150kg |
