Test Standard of TT-GVPT Gas Vapor Pressure Tester
ASTM D1267
Application of TT-GVPT Gas Vapor Pressure Tester
It is used to determine the vapor pressure of Liquefied Petroleum Gases (LPG), such as propane, butane, or their mixtures. Vapor pressure is a key parameter that affects the storage, handling, safety, and performance of LPG products
Features of TT-GVPT Gas Vapor Pressure Tester
- High temperature control precision, with PID auto-tuning function.
- After heating the heating tube, through the pump circulation, can make the rapid temperature rise.
- The design of mixing device is reasonable and has the characteristics of uniform mixing.
Technical Specification of TT-GVPT Gas Vapor Pressure Tester
| Model | TT-GVPT Gas Vapor Pressure Tester |
| Temperature control range | Room temperature ~100℃ |
| Temperature control accuracy | ±0.1℃ |
| Main heating power | 500W |
| Auxiliary heating power | 1500W |
| Vapor test projectile volume error | ±0.03 |
| Pressure gauge range | 0~1.6MPa |
| Water bath volume | 340X200X600mm |
