Application of TT-CT2000 Constant Loading Compression Testing Machine
It is suitable for compressive strength testing of bricks, stones, cement, concrete and other materials and can also be used for compressive performance testing of other materials
Technical Specifications of TT-CT2000 Constant Loading Compression Testing Machine
Model | TT-CT2000 |
Maximum test force | 2000kN |
Loading rate (MPa) | 0.3~1.0Mpa, stress speed greater than 1.0 can be entered manually ±5% |
Loading rate accuracy | 10%~100% |
Effective measuring range | Better than ±1% of the indication value |
Distance between upper and lower platen | 320mm |
Pressure plate size | 260x260mm |
Piston | Stroke: 50mm / Diameter: Φ250mm |
Maximum oil pressure | 40Mpa |
Motor power | 0.55kW |
Total power | 1.1kW |
Supply voltage | AC380V ±10%, 50Hz |
Mainframe dimension | 580x500x1400mm |
Controller dimension | 900x700x860mm |
Weight | 900kg |
Standard Configuration ofTT-CT2000 Constant Loading Compression Testing Machine
Item | Qty |
Main unit | 1pc |
Main cylinder | 1pc |
Pressure sensor | 1pc |
Lifting motor | 1pc |
Protective cover | 1set |
Controller | 1pc |
Electro-hydraulic servo oil source system | 1set |
Fuel tank | 1set |
Fuel pump | 1pc |
Oil pump motor | 1pc |
Pressure reducing valve | 1pc |
Digital valve | 1pc |
High pressure oil pipe | 1set |
Computer | 1set |
Software | 1set |
Operation Manual | 1pc |
Quality Certificate | 1pc |
Warranty Card | 1pc |
