Working Principle of TT-CPP250 Automatic Cloud & Pour Point Tester
Controlled cooling with automatic wax crystal detection for precise pour and cloud point analysis. The system monitors fluidity changes, uses an auto-tilting mechanism to detect flow, and records results automatically ensuring accurate, repeatable measurements compliant with ASTM and GB/T standards.
Test Standards of TT-CPP250 Automatic Cloud & Pour Point Tester
ASTM D97, ASTM D2500, GB/T 510, and GB/T 3535 standards.
Application of TT-CPP250 Automatic Cloud & Pour Point Tester
It is commonly used in petroleum refineries, power plants, chemical industries, commodity inspection agencies, and scientific research institutions.
Application fields
- Low-temperature performance testing of lubricating oils
- Examination and analysis of diesel and fuel oils
- Quality assurance of petrochemical products
- Laboratory testing in refinery operations
- Fuel oil assessment in power generation facilities
- Inspection and certification organizations
- Scientific research and material development centers
- Monitoring of petroleum quality in industrial applications
Features of TT-CPP250 Automatic Cloud & Pour Point Tester
- Fully automated operation including cooling, detection, tilting, and result calculation without manual involvement
- Intuitive LCD touchscreen interface for simple and convenient operation
- Wide temperature control capability ranging from heating up to 50°C and cooling down to -70°C
- High-efficiency compressor refrigeration system for rapid cooling and long operational life
- Automatic detection of results with integrated thermal printing for documentation
- Built-in automatic tilting mechanism in accordance with international testing standards
- Operation in dual modes including rapid testing and standard testing according to user requirements.
- Adjustable cooling rates and customizable testing procedures
Technical Specifications of TT-CPP250 Automatic Cloud & Pour Point Tester
| Model | TT- CPP250 |
| Temperature Control Range | Room temperature to -70°C |
| Measurement Range | Room temperature to -60°C |
| Cooling Capability | Temperature drop >15°C within 10 minutes |
| Measurement Accuracy | ±1°C |
| Resolution | 0.1°C |
| Sample Capacity | 1 sample |
| Display Mode | LCD touchscreen |
| Printer | Built-in thermal printer |
| Power Supply | AC 220V ±10%, 50Hz |
| Power Consumption | <300W |
| Rated Power | 1500W |
| Ambient Temperature | 0°C ~ 40°C |
| Relative Humidity | ≤85% |
| Instrument Weight | 50 kg |
| Dimensions | 500 × 490 × 800 mm |
