Application of TT-CMDR10 Computerized Moving Die Rheometer
It is a precision testing instrument used in the rubber industry to evaluate the curing characteristics and rheological properties of rubber compounds during the vulcanization process.
Test Standards of TT-CMDR10 Computerized Moving Die Rheometer
GB/T9869.3-2025, ASTM D5289-2019a, ISO 6502:1991
Features of TT-CMDR10 Computerized Moving Die Rheometer
- Can simultaneously print and record the vulcanization curve and the upper/lower die cavity temperature curves;
- Printed data is comprehensive, practical, storable, and has statistical analysis functions;
(ML、MH、T10、T30、T50、T70、T90、TS1、TS2、VC1、VC2 , Factory Name, Compound Number, Date, etc.)
- Three main control technologies, leading domestically:
- Variable Structure Predictive Control (VSPC) technology, greatly improving temperature control accuracy;
- Modular structure control technology, improving instrument reliability and stability;
- New top-mounted structure for torque measurement, eliminating various interferences, keeping curves smooth, and improving data repeatability;
- Test data can be exported, specifically for the needs of various researchers writing papers
- Die cavity structure and anti-slip groove shape are the same as Monsanto (now named ALPHA); the die cavity is a fully sealed structure.
Technical Specifications of TT-CMDR10 Computerized Moving Die Rheometer
| Model | TT-CMDR10 |
| Temperature control range | Ambient temperature ~ 230°C; Temperature Display Resolution: 0.1°C; Temperature Accuracy: ≤ ±0.3°C |
| Heating time | Ambient temperature ~ 185°C, approx. 8 min |
| Torque Range | 0 ~ 10 N.m |
| Torque Display Resolution | 0.001 N.m |
| Torque Measurement Accuracy | ±0.3% |
| Oscillation Frequency | 1.7 Hz (100 r/min) |
| Oscillation Amplitude | ±0.5° |
| Temperature Recovery Speed | Time for the test compound placed in the die cavity to recover to the set temperature ~ 45 seconds;
|
| Machine Dimensions (LWH) mm | 570 * 524 * 1203 mm |
| Machine Cabinet Dimensions (LWH) mm | 620 * 525 * 519 mm |
| Machine Weight | 230 kg |
Standard Configuration of TT-CMDR10 Computerized Moving Die Rheometer
| Items | Qty |
| Host and Accessories | |
| Main Unit | 1 set |
| Computer | 1 set |
| Printer | 1 set |
| Power cord (250V / 10A) | 1 pc |
| Communication line | 1 pc |
| Mold Cavity Sealing Ring (consumable) | 10 pcs |
| Fine Brass Wire Brush | 1 pc |
| Screwdriver | 1 pc |
| Hex Key Set | 1 set |
| Gloves | 2 pairs |
| Brush | 1 pc |
| Operating Video | 1 pc |
| Operating Manual | 1 pc |
| Quality Certificate | 1 pc |
| Warranty Card | 1pc |
