Heat Seal Tester Standards:
ASTM F2029-2016, YBB 00122003-2015, QB/T 2358-1998
Heat Seal Tester Features:
- Heat sealing with five points can set five different temperatures.
- Upper and lower heat seal bars have independent temperature control and can be set separately.
- Use compressed air, pneumatic drive.
- Automatic and manual modes; use footswitch for manual mode.
- Can customize size, shape, and smoothness of heat seal bar.
- Can upgrade heat seal bar with anti-sticking function.
- Temperature calibration is simple.
Heat Seal Tester Specifications:
| Item | Technical parameters |
| Temperature range | Room temperature~300℃ |
| Temperature precision | ±1℃ |
| Seal time range | 0.1s~999.9 S |
| Pressure range | 0.05~0.8Mpa |
| Heat seal area | Upper bar: 35×10mm × 5 sections, the lower bar has silicone pad as a buffer;(Can customize all kinds of specifications) |
| Heat seal method | two ways: automatic or manual, external air cylinder |
| Gas source | compressed air |
| Power | 2000W |
| Power supply | AC220V 50Hz |
| Weight | 55 kg |
| Instrument size | 700mm × 400mm × 540mm |
Heat Seal Tester Configuration List:
| A, Spare parts | ||||
| NO. | Name | Remark | Quantity | |
| 1 | Power cable | 3*0.75 10A 1.8 M | 1 PC | |
| 2 | Footswitch | FS-1 | 1 PC | |
| 3 | Allen wrench | 1 PC | ||
| 4 | Cross screwdriver | 6-10mm | 1 PC | |
| 5 | Wooden box | 1 PC | ||
| 6 | Keys | 1 PC | ||
| B, Optional parts | ||||
| NO. | Name | Unit | Quantity | Remark |
| 1 | Metrology Certificate | Optional | ||
| 2 | Air compressor | Optional | ||
| C, User provide | ||||
| 1 | Power supply 500w 220V 10A three holes socket ground wire | |||
| 2 | Air source (such as air compressor) specification 2.5HP、8KG pressure | |||
| 3 | High-pressure air pipe（Φ8mm plastic pipe) | |||
| 4 | Air filter (filter dust, filter oil, filter water) | |||
