TESTRON provides the CNC miller with pipe samples templates according to ISO 6259 types 1, 2 and 3.
Moreover, the inclusion of inbuilt machining programs and special clamping devices in TT-70CNC specimen milling machine enhances its usability and efficiency. This feature simplifies the process of preparing samples for different test bar shapes, making it convenient for users to meet the requirements of various tests with precision and ease.
Test Standards of TT-70CNC Specimen Milling Machine:
- ISO 179/180
- ISO 527
- ISO 6259
- ISO 16770
- ASTM D 638
- ASTM D 1822
Features of TT-70CNC Specimen Milling Machine:
- Pre-configured machining programs.
- Protective doors with safety lock.
- Clean workstation thanks to machine enclosure.
- Delivered with workbench.
Main frame features of TT-70CNC Specimen Milling Machine:
- The CNC milling machine is a table-top unit controlled by computer.
- Equipped with a specialized sample loading device, up to five test bars can be produced in one milling process.
- A swarf extraction system ensures the workstation remains clean.
- Rigid Aluminum alloy frame with a thickness of 15mm ensures its strength and stability.
- The CNC machining center technology is introduced for precision machining.
- Thanks to the frequency adjustable spindle speed, the speed can be variable adjusted, with maximum speed up to 24000r/min.
- Equipped with large flow refrigeration water pump, largely improves the machine’s lifetime.
- Axis limits are introduced to avoid accidental operation or collision.
- Equipped with a manual hand wheel, which is convenient for manual knife alignment and micro-adjustment.
Controller Features of TT-70CNC Specimen Milling Machine:
- The control system is based on the NCStudio control software developed under the Win7 platform, with simple interface and easy operation.
- Pre-configured machining programs for all common bar shapes and visualization via Windows makes it very easy to operate the milling machine. The program can also be manually edited with the help of CAD or other design software.
- The software has the functions of machine track, machine simulation, program editing, manual control, automatic control, etc.
- Since the general procedure is for milling dumbbell type sample, two dumbbell programs (ISO 6259) are pre-configured (other shapes can be customized).
Technical Parameters of TT-70CNC Specimen Milling Machine:
| Specimen thickness: | 3mm to 70 mm |
| Outside pipe diameters: | φ50 mm to φ120 mm |
| Plate length: | ≤150 mm |
| X axial travel: | 300 mm |
| Y axial travel: | 400 mm |
| Z axial travel: | 100 mm |
| Spindle speed: | ≤24000 r/min |
| Repeatability: | 0.05 mm |
| Power supply: | 220V 50Hz 3,3Kw |
| Dimension: | 850mm×780mm×1050mm |
| Weight: | 230 kg |
