TT-600 Rebar Corrosion Detector Features
● Non-destructive testing the corrosion in rebar.
● Detection of the corrosion condition of the rebar accurately and conveniently by field potential measurement.
● Possibility to store, view, delete data and transfer all readings to PC with USB interface and serial port.
● Faster and more accurate processing of data, presentation of test area and reading as numbers or graphics.
● Display of measurement values in 9 grey-scale or colorful graphics.
● Permanent copper/copper sulphate reference electrodes to measure electrical potentials.
TT-600 Rebar Corrosion Detector Technical Specifications
| Measuring method | Potential measurement | |
| Measuring range | ±1000mv | |
| Resolution | 1mv | |
| Memory | Mass storage | |
| Space between testing points | 1～100cm adjustable | |
| Interface | RS232 and USB | |
| Power supply | AA batteries (LR6)×6 | |
| Operating temperature | -10℃～+40℃ | |
| Relative humidity | ＜90%RH | |
| Dimensions | Main unit | 210mm×153mm×90mm |
| Probe | Φ30mm×120mm | |
| Weight | Main unit | 880g |
| Probe | 100g | |
TT-600 Rebar Corrosion Detector Standard Delivery
| Main unit | 1 |
| Electrode | 2 |
| Signal cable | 2 |
| USB connecting cable | 1 |
| RS232 connecting cable | 1 |
| Connecting bar | 1 |
| Extension cable | 1 |
| Clamp | 1 |
| Hygrothermograph | 1 |
| Measuring tape | 1 |
| AA battery (LR6) | 6 |
| Shoulder strap | 1 |
| Instruction manual | 1 |
| TIME certificate | 1 |
| Warranty card | 1 |
