Standard:
IEC 60794-1-2-E6
Technical Specifications:
| Bending angle | ±90° degree |
| Max. bending cycles | 1 – 9999 |
| Frequency range | 10 – 30 cycles/min |
| Bending radius (mm) | 25, 50, 75, 100, 150, 500 (others upon request) |
| Mass of weights for applying tension | Weight structure 27.5kg, 3 pieces of 5kg weight increment, 1 piece of 2.5kg weight increment. |
| Dimensions (L*W*H) | |
| Working frame | 3,000*720*2,500 mm |
| Control console | 400*300 * 800 mm |
| Power | 3-phase 4-wire, 50Hz, 1 kW. |
