It is designed to notch specimens for charpy & Izod impact test. 20 specimens may be clamped at one time and at least 60 specimens may be notched in 10 minutes. It allows a perfect reproducibility of the notches, increases working efficiency, and reduces the labor intensity.
| Item | Specifications |
| Model | TT-ANM-20 Motorized Notch Maker |
| Knife stroke | 90mm |
| Cutting speed | 30mm/min |
| Notch specification | According to the knives’ specification |
| Feed mode | Hand feed |
| Feed stroke | 10mm |
| Dimension | 400mm (L)×270mm(W)×300mm(H) |
| Weight | 50 Kg |
| Power supply | 220V/50HZ |
| Knives specifications | Type A: 45º±0.2 º r=0.25mm ±0.05mm(standard)Type B: 45º±0.2º r=1.00mm±0.05mm(option) |
