Elmendorf Tear Tester Standards:
ASTM D1922, ASTM D1424, ASTM D689, ISO 13937-1, ISO 6383, ISO 1974
Elmendorf Tear Tester Features:
- LCD display test data.
- Can test independently without a computer; auto process data.
- The built-in printer can print out reports.
- Pneumatic hold and release device.
- Software: simple interface, easy to use; real-time displays test data and curve;
- Can export professional test report.
Elmendorf Tear Tester Specifications:
| Item | Technical Parameters |
| Test range | 0-6400gf 0-18000mN |
| Tearing arm | 104±1mm |
| Initial tearing angle | 27.5°±0.5° |
| Indication error | within ±0.5% in 20%-90% of max range |
| Gas supply pressure | 0.2-0.4Mpa (user provides gas supply) |
| Relative fluctuation | within 1% |
| Gas supply port | Φ6mm polyurethane pipe |
| Instrument size | 430mm x370mm x 650mm |
| Weight | 50kg |
| Power | 100W |
| Power supply | AC220V 50Hz |
Elmendorf Tear Tester Configuration List:
| A, Spare parts | ||||
| NO. | Name | Remark | Quantity | |
| 1 | Power cable | 3*0.75 10A 1.8M | 1 PC | |
| 2 | Data cable | RS232 nine-pin | 1 PC | |
| 3 | Standard weights (G） | 110, 220, 440, 880, 1730, 3470 | 6 PCS | |
| 4 | Software flash disk | 4G | 1 PC | |
| 5 | Wide blade | 1 Box | ||
| 6 | Cross screwdriver | 6-10mm | 1 PC | |
| 7 | Allen wrench | M3 | 1 PC | |
| 8 | Wooden box | 1 PC | ||
| B, Optional parts | ||||
| NO. | Name | Unit | Quantity | Remark |
| 1 | Metrology Certificates | Optional | ||
| 2 | Air compressor | Optional | ||
| 3 | Computer | Optional | ||
| C, User provide | ||||
| 1 | Power supply 500w 220V 10A three holes socket ground wire | |||
| 2 | Gas source (such as Air compressor) specification 2.5HP、8KG pressure | |||
| 3 | High-pressure air pipe（Φ6mm plastic pipe) | |||
| 4 | Air filter (filter dust, filter oil, filter water) | |||
