Standards
- ISO 6964
- GB/T 2951.8 & GB/T 13021
- JTG E50 T1165
- IEC 60811-4-1
Features:
- LED display, up to set 30 temperature program segments
- Heating furnace body and control system integration design, convenient for operation
- Temperature program section manual input, automatic storage, just one button to start the test
- Nitrogen and oxygen gas instrument automatic switching, equipped with high-precision floating ball gas flowmeter
- Rapid cooling device is optional, realizing rapid cooling of temperature and improve the utilization efficiency
- Double doorknob furnace door design, convenient for taking and charging the material
- Thanks to Nano blanket new insulation material, which achieves the excellent thermal insulation effect and the finance high uniformity
Technical Parameters:
- Temperature: room temperature to 1000 ℃
- Furnace tube size: Ф 30 mm X 500 mm
- Heating element: resistance wire
- Display mode: LED
- Temperature control: PID programmable control, automatic memory temperature sections
- Power supply: AC220V/50HZ/60HZ 1KW
- Gross weight: 30kg
Configuration list
- Main frame
- Burning boat tray
- Power cord
- Burning boats (10 pieces)
- CD for operations video
- Oxygen airway, nitrogen airway and exhaust airway, 5m for each
- Operation manual
- Spoons and a pair of medicine tweezers
- Custom pressure reducing valve joint and quick joint (2 pieces)
