Joints Leak Tightness Tester Standards:
EN DIN 1277, ISO4422, ISO13844
Joints Leak Tightness Tester Features:
- The industrial LCD display is convenient to input and checks test information, including test
parameters, test results, and test curves, etc. - Test data can easily be exported to the user’s PC via a USB stick for further processing and report generation.
- Hydraulic type pipe deflection device at radial direction, high precision digital gauge display, as well as the self-aligning centering function, ensure the operation easier.
- Different supporting blocks are introduced for different pipe fittings.
- Angular deflection at four directions can be collected.
- Unique design for sample clamping system makes the sample installation more convenient.
Joints Leak Tightness Tester Technical parameters:
- Test station: 1
- Pipe diameter(DN): (63 to 400)mm or (200 to 710)mm
- Pressure range: 0 to (-0.08) MPa
- Pressure display accuracy：0.001MPa
- Pressure control accuracy (MPa): -0.01±0.002 / -0.03±0.0015 / -0.08±0.002
- Max. angle of deflection: 2.5°
- Power supply: 220VAC 50Hz 1.0kW
