Bursting Strength Tester Standards:
ASTM D2210, ISO 2759, GB/T 6545, JIS P8112, JIS L1018, TAPPI T403
Bursting Strength Tester Specifications:
| Model | high pressure |
| Speed of pressurization | 170 ± 15 ml/min |
| Pressure gauge | Diameter 4” |
| Capacity | 20, 50, 100 (choose two) |
| Plate diameter-Upper plate | 31.5 ± 0.05 mm |
| Plate diameter-Lower plate | 31.5 ± 0.05 mm |
| Pressurization patterns | pressurization return |
| Dimension | 35 x 53 x 50 cm |
| Weight | 60kg |
Bursting Strength Tester Accessories:
Rubber film low pressure
This accessory for the bursting strength test is placed under the test specimen plate. After pressurization, the glycerin will hold up the rubber film and then break the test specimen.
This is a test consumable that will be fouled, fatigued or broken when used for a period of time and will need to be replaced if necessary.
Note: Low pressure rubber film is applicable to the range 0~10kgf/c㎡
Rubber film high pressure
This accessory for the bursting strength test is placed under the test specimen plate. After pressurization, the glycerin will hold up the rubber film and then break the test specimen.
This is a test consumable that will be fouled, fatigued or broken when used for a period of time and will need to be replaced if necessary.
Note: High pressure rubber film is applicable to the range 10~75kgf/c㎡
Aluminum foil
Standard sheet for calibration.
Regular use of standard aluminum foil to check the condition of the testing machine. If the deviation is too large, it is recommended to replace a new rubber film.
