TEST STANDARDS
ASTM D240, GB/T 213
Note: this tester can conform to but not limit to the standards above, for more standards
conformance, please contact us.
FEATURES:
-
-
- It adopts technology of single chip machine, LCD screen, high accuracy temperature sensor and high-performance A/D conversion device.
- The test procedure is fully automatic. After placing the sample and inputting the right parameters, the instrument will finish all the procedures without manual interference. It will print the test data directly after the test is over.
- It adopts sealed oxygen bomb. The whole structure adopts stainless steel. The strength is enough to resist 20MPa hydrostatic test under room temperature.
- The inner water container is made of stainless-steel sheet and the cross section is pyriform. With electric stirrer to make sure the uniform temperature in water bath.
- External water jacket is a double layer container. It will be filled fully with water when testing. The stirrer in the water jacket will work to ensure the uniform temperature and create the constant temperature condition for test.
-
KEY SPECIFICATIONS:
| Items | Technical Parameters |
|---|---|
| Heat capacity | (14,400~ 15,000) J/K |
| Resolution | 0.001K |
| Measuring range | (10~35)℃ |
| Measurement accuracy: | ≤0.2%≤±60J/g |
| Pressure endurance of bomb | 20MPa |
| Display | LCD screen |
| Power supply | AC220V, 50HZ |
| Total power consumption | ≤150W |
| Ambient requirement | Temperature: (15~28)℃, the fluctuation is not more than 1℃ during one test; Relative humidity: ≤85% |
| Dimensions | 600*480*460mm(L*W*H) |
OPTIONAL ACCESSORIES:
