UV Weathering Resistance Test Chamber Features:
- UVA-340, UVB-313 Fluorescent UV lamps (8) – 40 W
- Black Panel Temperature (BPT) at controlled, BPT 30~70℃
- Temperature from Ambient to +90℃
- Build-in water tank and automatic water supply
- Programmable color display touch screen controller
- Ethernet and USB
- Easy to mount samples
UV Weathering Resistance Test Chamber Model:
Model | UV-SI-260 | |
Internal Dimension (mm) | 450*1170*500 | |
Overall Dimension (mm) | 680*1300*1500 | |
Specimen Holder Size(mm) | 75*150 | |
Specimen Capacity | 56 Pieces | |
Irradiation Source | Fluorescent UV lamps (8) – 40 W | |
Parameter | Temperature Range | Ambient ~ 90 ℃ ±2℃ |
Black Panel Temperature (BPT) | 35 ~ 80 ℃ | |
Humidity Range | ≥95% RH | |
Bandwidth | 290 ~ 400nm | |
Irradiance Control | 0.3~20 W/㎡ | |
Water Spray Cycle | 1~9999H59M (Adjustable) | |
Distance of Specimen and lamp | 50mm | |
Constructor | Heating Element | Nichrome heater |
Controller | Programmable color LCD touch screen controller | |
Ethernet connection, PC Link, USB | ||
Water Supply System | Automatic water supply | |
Water purification system | ||
Build-in Water Tank(mm) | 350*350*300 | |
Safety Device | Over-temperature Protection; Over-current Protection; Water Shortage Protection; Earth leakage Protection; Phase Sequence Protection | |
Material | Exterior Material | Steel Plate with protective coating |
Interior Material | SUS304 stainless steel | |
Thermal Insulation | Polyurethane foam and insulation cotton | |
Power Supply | 380V 50Hz | |
Standard | ISO4892-1,ISO4892-3, ASTM G154, ASTM D4329, ASTM D458, ASTM C125, ASTM C1442, ASTM C1519, ASTM C793, ASTM D1148, ASTM D3424, ASTM D3451, ASTM D410, ASTM D481, ASTM D657, ASTM D6662, ASTM D750, ASTM D904, GM 9125P, ISO 29664 | |
Maximum Noise | 65 dBA | |
Environmental Conditional | 5℃~+35 ℃ ≤85% RH |
UV Weathering Resistance Test Chamber Optional Accessories:
Number | Name | Description | |
---|---|---|---|
No.1 | UV lamp | Fluorescent UV lamps – 40 W | |
No.2 | Sample holder | UV-holder size: 75* 150mm Thickness: 5mm | |
No.3 | Temperature heater |
|
