Spectrodensitometer Features:
- Nearly perfect accuracy, is the only density meter series measured color by spectral sensor technology, measuring geometry is 45°/0°, meets DIN&ISO standard, with high accuracy. A highly consistent measurement provides you with comparable color measurement results at any time and anywhere.
- Large graphics display screen for your convenience, easy to read, multiple languages (including English) display all menu commands, which can meet your needs for any measurement operation.
- The reliable and unique design concept of the measurement target window helps users locate easily and accurately, so that accurate measurement values can be obtained each time. The unique portable shape design has led to the innovation of density measurement.
- A variety of measurement apertures including the standard measurement diameter 3.4mm, with a variety of measurement apertures to choose from: 2.0mm measurement aperture (excluding polarizer); 6.0 mm diameter; 1.6mm x 3.2mm micro aperture.
- Built-in database of X – Rite 528 Spectrodensitometer and X – Rite 530 Spectrodensitometer, can use your own color standards or download from the built-in PANTONE color database, can immediately find the closest match colors from a color database by measuring.
Spectrodensitometer Specifications:
| Item | Technical Parameters |
| Measurement geometry | 45º/0º, meets ANSI, DIN & ISO Standards |
| Measurement diameter | Φ3.4mm as standard; optional:6.0mm, microaperture:1.6 x 3.2mm |
| Light source | Pulse type gas filled tungsten lamp, color temperature2856° |
| Spectral range | 400-700m |
| Illuminant types | A,C,D50,D55,D65,D75,F2,F7,F11,F12 |
| Standard viewing angle | CIE2°and 10° |
| Response types | T,E,I,A,G,Tx,Ex,Hi-Fi |
| Measurement range | Density:0.00D-2.50D reflectance:0-160% |
| Measurement time | A single measurement is about 1.4 seconds, and continuous measurement is about 0.9 seconds in fast reading mode |
| Warm up time | unnecessary |
| Repeatability | ±0.005D 0.00-2.00D;±0.010D 2.00-2.50D |
| Inter-instrument agreement | 0.01D or 1%for typical printing processes within 0.40△Ecmc measure 12 pieces of BCRALL |
| Data storage | More than 1400 pieces of sample（528 and 530） |
| Serial data interface | RS-232 |
| Rechargeable power supply | Nickel hydride rechargeable battery 4.8V@1250mAH |
| Charging time | Approx. 3 hours |
| Weight | 1050g（2.3 pound） |
