TT-OTR100 Oxygen Permeability Analyzer

Applications of TT-OTR100 Oxygen Permeability Analyzer

Oxygen transmission rate testing is applicable to a wide range of materials and packaging formats including plastic films (PP, PET, PE, PVC, BOPP, CPP, PLA, PBAT, PBS), composite films (paper-plastic, metal, co-extrusion, aluminized), pharmaceutical sheets (PP, PVC, PTP), coated and specialty papers, rubber sheets, medical plasters, sanitary products, rigid containers (bottles, cans, barrels), flexible packages (bags, boxes, pouches), cosmetic and food packaging (toothpaste tubes, jelly cups, yogurt cups), solar backsheets, package closures, and pipes of various materials.

Test Standards of TT-OTR100 Oxygen Permeability Analyzer

ASTM D3985, ASTM F2622, ASTM F1927, ASTM F1307, ISO 15105-2, DIN 53380-3, JIS K-7126-B

Features of TT-OTR100 Oxygen Permeability Analyzer

Patented core technology, efficient and accurate testing

• High precision imported oxygen sensor with high sensitivity, ultra-high stability and ultra-low failure rate, with a resolution of 0.0001 cm3/(m2·24h·0.1MPa).
• The new pneumatic air circuit control system, the automatic fixture clamps the sample,

which is convenient and labor-saving and has excellent sealing performance.

Automatic temperature and humidity precision control

• Temperature control: bi-directional automatic temperature control of the semiconductor refrigeration chip, the temperature control accuracy is higher, up to 0.1 ℃.
• Humidity control: automatic humidity control with double airflow humidity method, stable humidity, high precision, accurate humidity to ±2%RH.

Meet the test requirements of wide range and high applicability

• The instrument is equipped with a single cavity, which is compact and flexible, saving space.
• The test range is wide, and the test lower limit is as low as 0.01 cm3/(m2 24 h 0.1 MPa), which can meet the test requirements of high, medium and low barrier materials. With the addition of adapter accessories, it can measure the oxygen transmission rate of bottles, bags, bowls and other containers.

Excellent appearance, convenient operation, real-time visualization curve

• The product is designed from the perspective of ergonomics and technical aesthetics, with exquisite 3D printed shell and lines Smooth, stylish and beautiful, novel and unique.
• The host is embedded with an 11.6-inch high-resolution color touch screen with clear views, sensitive touch and easy operation.
• The instrument is fully automatic operation, one-button test, automatic judgment, automatic shutdown.
• Real-time display of six sets of curves including permeation-time, temperature-time, humidity-time, nitrogen flowtime, oxygen flowtime, and concentration-time. The curves support preview and hide functions.

Intelligent operating system, global certification

• Self-developed intelligent operating system, modular icons, stylish color matching, humanized settings, intuitive and convenient operation.
• According to the GMP appendix computer system design, the test process parameters can be set flexibly to meet different standard requirements.
• With audit trail (log trace, test trace) function, it can meet the needs of data traceability. Different levels of system operation authority can be set.
• Personalized test reports can be set on demand, data output in multiple formats, electronic signatures, and online submission of audit reports are supported.3

Offline or online detection

• The instrument has its own operating system, which can be tested independently from the computer, and the data can be processed automatically. The instrument is equipped with a computer interface and can also be connected to a computer for online detection.

Professional calibration service, accurate and reliable data

• Our company has the gas transmission rate “National Standard Substance Grading Certificate” approved and issued by the “General Administration of Quality Supervision, Inspection and Quarantine of the People’s Republic of China”, the reference material number (GBW(E) 130497 / GBW(E) 130498); The national reference material is used to calibrate and test the instrument to ensure the accuracy, versatility and authority of the test data.

Laboratory Intelligent IoT Platform

• The instrument can be connected to the Internet of Things platform to realize network digital management.
• Remote authorization to log in to the IoT platform can realize functions such as managing experimental data, remotely diagnosing and solving faults.
• Customers can download the required instrument information, documents, and operation videos on the platform by themselves.

Technical Specification of TT-OTR100 Oxygen Permeability Analyzer
