Application of TT-MIG09 Fully Automatic Overall Migration Tester
TESTRON TT-MIG09 Fully automatic overall migration tester is suitable for various utensils, containers, food packaging films, cans or other various food tools, pipes and so on with material of polyethylene, polystyrene, polypropylene, perchloroethylene
resin to determination of the dissolution of products in different soaking solutions.
Through the determination of evaporation residue, the analysis of leaching index is performed to meet the different needs of product applications. (EU) 10/2011 and its amendment (EU 2020/1245), as well as EN1186-1-12 and EN13130
Features of TT-MIG09 Fully Automatic Overall Migration Tester
- Solvent evaporates in a fully closed system, manual intervention not requested.
- Built-in water bath evaporation system, automatically water bath refilling.
- The parameter curves are displayed in real time during the test.
- The heating system using the embedded electromagnetic device, temperature control program step calculation, and avoid over temperature.
- Save test records automatically, provide a convenient query function, easy to manage.
- Come with external computer software operating system, support Windows 10 touch screen operation
- Nine workstations, each with independent test data; can test nine samples at the same time.
- Professional test report helps improve test efficiency.
- Functional modularity, independent testing, calibration and other functions, strong data analysis ability, easy operation.
Technical Specifications of TT-MIG09 Fully Automatic Overall Migration Tester
| Model | TT-MIG09 |
| Test range | 0~80g (residue weight) |
| Test precision | ±0.2mg |
| Resolution | 0.1mg |
| Temperature range | Room temperature~120℃ |
| Temperature | ±2℃（conventional） |
| Heated air circulation speed | 0.2 m/s |
| Test sample | 0~200mL |
| Test sample number | 1~9 pcs (each sample is independent) |
| Test chamber volume | 93L |
| Instrument size | 900×865×800mm |
| Power | 4500W |
| Power supply | AC 220V, 50Hz |
Standard Configuration of TT-MIG09 Fully Automatic Overall Migration Tester
| Item | Qty |
| Evaporating dish | 9 pcs |
| communication cable | 1 pc |
| Gas pipe | 1 pc |
| Steel pipe | 1 pc |
| 200g weight | 1 pc |
| Breaker | 9 pcs |
| Thermostat water bath | 1 pc |
| Computer set (optional) | 1 set |
