Test Standard of TT-LPGD Liquified Petroleum Gas Density Tester
ISO 3993
Application of TT-LPGD Liquified Petroleum Gas Density Tester
It is used to accurately measure the density of LPG products such as propane, butane, and their mixtures. It is widely used in refineries, LPG bottling plants, distribution terminals, and quality control laboratories. By ensuring correct density, the tester helps with product classification, blending control, and verifying consistency in commercial and domestic gas supplies.
Features of TT-LPGD Liquified Petroleum Gas Density Tester
- The instrument is mainly composed of control system, refrigeration system, constant temperature bath and pressure densitometer cylinder.
- The constant temperature bath uses stainless steel material, fluorescent lamp illuminates on both sides, observe through organic glass transparent window, the light inside the bath is even and soft.
- High temperature control precision, with PID auto-tuning function.
- To meet the pressure requirements of the experimental method, the pressure densimeter cylinder is assembled with hard glass cylinder and cast copper plug, and the external protection net is also installed.
Technical Specification of TT-LPGD Liquified Petroleum Gas Density Tester
Model | TT-LPGD Liquified Petroleum Gas Density Tester |
Input power | 1250W |
Refrigeration System Power | 425W |
Heater Power | 800W |
Temperature Control range | 10~25℃ |
Temperature control Accuracy | ±0.2℃ |
Overall Dimension | 330X530X810 mm |
Weight | 45Kgs |
