Application of TT-IST1000 Intelligent Seal Tester
- Plastic Composite Bag
It is suitable for the pressure rupture test of various plastic films, aluminum films, paper-plastic composites, aluminum-plastic composites and other packaging bags.
- Hose test
It is suitable for packaging hoses of various cleaning products and other fields. The hose can include toothpaste tubes, facial cleanser, cosmetics, various medicinal ointment tubes, food packaging tubes.
- Creep test
Applicable to the creep performance test of various packaging bags, boxes, etc.
- Creep to rupture
Suitable for performance testing from creep to rupture of various packaging bags, boxes, etc.
- Blister Pack Burst Test
Suitable for pressure test of various blister packs.
- Aerosol Valve Test
It is suitable for testing the sealing performance of various aerosol valves. Aerosol valves include
various insecticides, mousses, jelly water, medicinal sprays, self-spray paints, etc.
- Three-sided heat-sealing material
It is suitable for the pressure test where only three sides of the packaging bag are heat-sealed and one side is open
- High-pressure test
The test pressure can reach up to 1.6 MPa
- Anti-theft bottle cap
It is suitable for the sealing performance test of various anti-theft bottle caps. Anti-theft bottle caps can include cola bottle caps, mineral water purified water bottle caps, beverage bottle caps, vegetable oil barrel caps, non-staple food condiment caps (soy sauce, vinegar, cooking wine, etc.), easy-open three-piece cans (beer, beverage cans, etc.), paper packaging cans (cylindrical, various potato chips and shrimp crackers), etc.
Test Standards of TT-IST1000 Intelligent Seal Tester
ASTM F1140, ASTM F2054, ASTM F2095, ASTM F2096, ISO 11607, YY/T 0681.3, YY/T 0681.5, YY/T 0681.9
Features of TT-IST1000 Intelligent Seal Tester
- Positive pressure design principle, simple operation, stable and reliable performance.
- Double test method of expansion inhibition and expansion non-inhibition.
- Rupture test, creep test, creep-to-rupture test, multiple test modes to choose from One-key’ operation in the test process, intelligent and high-test efficiency.
- The host is embedded with a 7-inch high-resolution color LCD screen, with clear views, sensitive point control, and easy operation.
- Test accessory support, flexible test mode, compatibility and diversification.
- The test range is optional, and the test range is wide, and the application field is wide.
- User graded permission setting, meeting GMP requirements, test record auditing, and tracking functions.
Technical Specifications of TT-IST1000 Intelligent Seal Tester
Model | TT-IST1000 | |
Test range | 0.1 Kpa~1 Mpa | |
Resolution | 0.1 Kpa | |
Test accuracy | 0.1 Kpa | |
Testing time | 1~1000 s | |
Test type | Burst, leak, creep, bubble method | |
Type of packaging | Soft package, semi-plastic package, all-plastic package | |
Air pressure | 0.5 Mpa~0.9 Mpa | |
Dimensions | 400 mm×415 mm×272 mm | |
Power supply | 220V 50Hz | |
Power | 150W | |
Weight | 10kg |
Working Principle of TT-IST1000 Intelligent Seal Tester
The sample is evaluated for airtightness and sealing performance through controlled air pressurization, either until the package bursts or until a specified pressure level is reached. Depending on the test requirement, different methods can be applied, including burst test, leak test, creep test, and bubble test in accordance with relevant international standards.
The results can be expressed through a combination of parameters such as test pressure, holding time, package position under test, and leak location, providing a comprehensive assessment of the packaging material’s sealing strength and integrity.
Test method of TT-IST1000 Intelligent Seal Tester
- Burst test
The instrument keeps increasing the pressure on the package until the package bursts. (Conforming to ASTM F1140, ASTM F2054, YY/T 0681.3, YY/T 0681.9 standards)
- Leakage test
After the package is inflated to reach a preset pressure, and maintain the required test time under this pressure, the pressure management and leak test are carried out according to the standard, and the test conditions of unconstrained or restricted plate can be selected. (Conforming to ASTM F2095, ISO 11607-1 standards)
- Creep test
A constant pressure is generated in the package, close to the burst limit, and maintained for a certain period of time, and the sealing performance is evaluated when the pressure is applied within the set time. Optional test modes: creep and creep to failure (Conforming to ASTMF1140, YY/T 0681.3 standards)
- Bubble test
Put the package in water, then pressurize the package to a predetermined pressure, and maintain the predetermined pressure for a preset time (in accordance with ASTM F2096, YY/T 0681.5 standards).
Standard Configuration of TT-IST1000 Intelligent Seal Tester
- Host
- Open inflatable fixture (unconstrained)
- pinhole fixture (unconstrained)
Optional Accessories of TT-IST1000 Intelligent Seal Tester
- Limiting plate (open inflatable fixture)
- Limiting plate (pinhole fixture)
- Bubble method fixture
- Air compressor
- Measurement certificate
- Computer
