Test Standards of TT-HAT500 Series Cross Hatch Tester
ISO 2409, ISO 16276-2, ASTM D3359, ASTM D3302, BS 3900 E6
Features of TT-HAT500 Series Cross Hatch Tester
- Precision cutting wheel with 6 or 11 blades
- Various blade spacing for different coating thicknesses
- Turnable cutter holder for curved and uneven surfaces
- Uniform cutting force through coating to substrate
- Suitable for single‑coat and multi‑coat adhesion testing
- Long‑life cutter with 8 cutting edges
- Durable, ergonomic wooden handle
Technical Specifications of TT-HAT500 Series Cross Hatch Tester
| Model | No. of Teeth | No. of Cutting Edges | Cutter Spacing | |
| For Cross Hatch Tester | For Cutters Only | |||
| TT-HAT501 | TT-HAT501A | 11 | 8 | 1mm |
| TT-HAT502 | TT-HAT502A | 6 | 8 | 1mm |
| TT-HAT503 | TT-HAT503A | 11 | 8 | 2mm |
| TT-HAT504 | TT-HAT504A | 6 | 8 | 2mm |
| TT-HAT505 | TT-HAT505A | 6 | 8 | 3mm |
| TT-HAT506 | TT-HAT506A | 11 | 1 | 1mm |
| TT-HAT501-1 | TT-HAT501B | 6 | 1 | 1mm |
| TT-HAT502-2 | TT-HAT502B | 11 | 1 | 2mm |
| TT-HAT503-3 | TT-HAT503B | 6 | 1 | 2mm |
| TT-HAT504-4 | TT-HAT504B | 6 | 1 | 3mm |
Standard Configuration of TT-HAT500 Series Cross Hatch Tester
| Items | Qty |
| Cross Hatch Cutter & Handle | 1 |
| Carrying case | 1 |
| Transparent Tape | 1 roll |
| Brush | 1 |
| Magnifier | 1 |
| Operation manual | 1 |
| Calibration Report/Certicate | 1 |
| Warranty Card | 1 |
