Digital Thickness Meter Standards:
ISO 4593, ISO 534, ISO 3034, ASTM D645, ASTM D374, ASTM D1777, ASTM F2251, TAPPI T411, DIN 53105, DIN 53353, JIS K6250, JIS K6328, JIS K6783, JIS Z1702, BS 3983, BS 4817, GB/T 6672, GB/T 451.3, GB/T 6547
Digital Thickness Meter Features:
- High precision (0.1μm), digital display, stable, easy to operate.
- Measuring mode: manual and automatic.
- Single point and multiple point measurement.
- LCD display, real-time display of max, min, average and current values.
- With built-in printer, can print test reports.
Digital Thickness Meter Specifications:
| Item | Technical Parameters |
| Test range | 0~3mm |
| Test resolution | 0.1μm |
| Number of test points | 0~30 Points |
| Space of sampling | 0~1000mm |
| Measure force | 0.5N |
| Measure head size | Φ5mm (can customize) |
| Working Temperature | 0~40℃ |
| Power | 1000W |
| Power supply | AC 220V，50Hz |
| Instrument size | 400×310×340mm |
| Weight | 25kg |
