Intelligent Compost Degradation Tester Standard:
ISO14855-1, ASTM D 5338, ASTM D 6400, JIS K 6953, GB/T19277.1
Intelligent Compost Degradation Tester Application:
Garbage Bag, Plastic Film, Straw, Courier Bag, Water Treatment Agent, Compost Biological Activity, Disposable Tableware, Agricultural Mulch Marine Environment, Biodegradability of Lower Plastics.
Intelligent Compost Degradation Tester Features:
Data is accurate and reliable
- High-precision gas mass flow controller to ensure the stability and accuracy of intake air flow.
- The original imported brand carbon dioxide sensor ensures the accuracy of the measurement results.
- Built-in cavity measurement calibration system, convenient to detect the accuracy of carbon dioxide and oxygen.
Easy to operate
- Professional software support, the software interface is simple and clear, easy to operate, and the test process can be set flexibly.
- Fully automatic operation, set the corresponding parameters, and test with one button.
- The software displays and records the experimental status and process parameters in real time.
- Professional test report generation can export files in Office, PDF, and other formats.
Advanced technology
- Each channel is independently set with gas flow and carbon dioxide (CO2) concentration measurement modules.
- Built-in automatic mixing system can customize mixing cycle and mixing time.
- PID simulation algorithm temperature control technology to achieve high-precision temperature control.
- Built-in leak detection system to ensure the air tightness of the gas path.
- Each channel can be freely combined, blank, reference, sample mode can be set freely, and independent testing.
- One-click analysis of test results, greatly saving laboratory human resources.
High test efficiency
- 18 chamber samples are independently tested, and data is collected separately for each chamber.
Intelligent Compost Degradation Tester Technical Parameter:
| Item | Technical parameter |
| Temperature control range | Room temperature ~80℃ |
| Temperature control accuracy | ±0.5℃ |
| Flow control range | 0.01~1L/min |
| Flow control accuracy | ±1.0%FS |
| Flow detection range | 0.01~2L/min |
| Flow detection accuracy | ±1.0%FS |
| Carbon dioxide detection range | 0~10000ppm |
| Carbon dioxide detection accuracy | 0~3000 ppm (±40ppm), 3000~10000 (±2%) |
| Oxygen detection range | 0~25% |
| Oxygen detection accuracy | ±1%FS |
| Pressure detection range | 0~200KPa |
| Pressure detection accuracy | ±1%FS |
| Air source pressure | 0.2～0.8Mpa |
| Air source interface | φ8 |
| Testing chamber quantity | 18 chambers |
| Testing chamber volume | 3.5L |
| Dimension | 3600mm*810mm*1930mm |
| Weight | 1100kg |
| Power | 3000W |
| Power supply | AC 220V，50Hz |
