Test Standard of TT-CRT Carbon Residue Tester
ASTM D4530
Application of TT-CRT Carbon Residue Tester
It is widely used in refineries, petrochemical plants, fuel testing labs, and R&D centers, this tester evaluates the coke-forming tendency of lubricating oils, fuel oils, and other petroleum-based products. It is essential for assessing product quality, refining processes, and fuel cleanliness especially for heavy fuels and residues used in high-temperature environments.
Features of TT-CRT Carbon Residue Tester
- 7-inch touch LCD screen displays the temperature, heating rate, running time and status of the combustion chamber of the instrument, and displays the temperature curve in real time.
- Equipped with steady flow and voltage stabilizer, more stable flow control and automatic switching.
- With the function of state display, it can measure 12 samples.
- It has the function of calculating test results and can calculate repeatability and reproducibility.
- It has the function of fault diagnosis and automatic alarm.
- LIMS interface can be customized according to user’s requirements to transmit test data.
Technical Specification of TT-CRT Carbon Residue Tester
| Model | TT-CRT |
| Heating rate | 10 ~ 15℃/min |
| Temperature range | Room temperature 500℃ |
| Temperature control Accuracy | 500℃±2℃ |
| Heating Power | 730W |
| Gas Demand | Nitrogen |
| External Dimensions | 260x400x690 mm |
| Weight | 28.5 Kgs |
Main Interface of TT-CRT Carbon Residue Tester
| The temperature rise and fall can be visually displayed through the curve. |
Accessories of TT-CRT Carbon Residue Tester
| Items | Picture | Qty |
| Furnace cover |  | 1 pc |
| Test tube rack |  | 1 pc |
| Test tube 4ml |  | 24 pcs |
| Test tube 2ml |  | 1 pc |
| Sample hook |  | 1 pc |
| φ4 PU Tube | – | 1pc |
| Nitrogen cylinder connector | – | |
| Waste liquid bottle |  | 1 pc |
| Motherboard battery | – | 1 pc |
| Mouse and keyboard | – | 1 each |
