Name: TT-6300 Drying Oven for Longitudinal Reversion Test
Rating: 5 (24 reviews)

TT-6300 Drying Oven for Longitudinal Reversion test

Longitudinal Reversion Test is a method of determining the level of internal stresses in pipes. This air conditioning chamber is suitable for drying, baking, melting and sterilization in industrial and mining fields, laboratories and scientific research institutions.

Test Standards of TT-6300 Drying Oven for Longitudinal Reversion test:

ISO 2505

Features of TT-6300 Drying Oven for Longitudinal Reversion test:

Internal oven material: SUS304 plate.
Heating elements: Ni-Cr Stainless steel plate type heater.
Microcomputer intelligent temperature controller, with the function of setting, measuring temperature double digital display and PID self-tuning, Accurate and reliable temperature control, with digital timer and heating power regulation function, working time can be up 6 days.
The circulating system, composed of low-noise German brand fans and suitable air ducts, makes the hot air forced convection vertically, keeps the uniform temperature in the working room.

Technical Parameters of TT-6300 Drying Oven for Longitudinal Reversion Test:

Internal dimension:	800x800x1000mm (can be customized)
Specimen length:	≤300mm
Specimen diameter:	630 mm
Temperature range:	50℃ to 250℃
Temperature fluctuation:	≤±1℃
Temperature resolution:	0.1℃
Power supply:	1.0KW AC220V 50HZ
