Features of TT-HMCA Halogen Moisture Analyzer
- 5” programmable color touch screen, an interface directly displays moisture, solid content, test temperature and other information.
- Built-in guided operation and voice prompts, operators can follow the graphical guidance to gradually complete the workflow and can adjust the size of the sound according to personal habits or directly off.
- Adopt imported German HBM weighing sensor, high precision zero temperature drift
- 500W high efficiency halogen ring lamp, fast heating, waterproof and explosion-proof, the heating chamber adopts pure stainless steel chamber cover, so that the sample is heated more evenly.
- PT100 temperature sensor, accurate temperature control, with waterproof anticorrosion and high temperature resistance
- Rich data processing functions, can be customized to add 100 test methods, can store 100 water results and average.
- The built-in database in the halogen moisture analyzer can save 2000 audit trail data. If the U disk function is optional, the tracking data will be updated to the U disk in real time when the U disk is inserted in the instrument, and countless data can be saved.
- Built-in RS232 interface can connect to thermal printer, label printer or computer, you can also choose USB interface.
- Instead of the national standard oven method, the way is very wide, suitable for moisture content testing and solid content testing in various industries.
- No installation and debugging, can be used out of the box; The real-time curve of the test process is displayed, and the moisture change is visually observed. The Halogen lamp moisture analyzer rich data display can display curves, time, real-time temperature, moisture, solid content, Automatic measurement, measurement process without care, measurement alarm reminder.
Benefits of Using the Halogen Moisture Testing Machine
Quick 2–5 minute test cycles using the halogen lamp reduce both energy usage and downtime, providing a better long term halogen moisture analyser cost compared to oven based methods.
The analyzer accepts a wide range of materials, from powders and granules to food, tea, paper, and raw chemicals, giving you a broad application spectrum for a single analysis system.
ISO traceable halogen moisture analyzer calibration and GLP capable data storage support compliance with internal quality systems and external audit standards.
Voice guided prompts, secure door interlocks, and automatic shutdowns reduce errors and improve safety:-especially in fast paced settings.
Secure password protection and audit logs prevent unauthorized access, while real time USB tracking preserves data integrity for regulatory compliance.
Applications of Halogen Lamp Moisture Analyzer Across Industries
Food & Beverage
Moisture content analysis of grains,flours, dried foods, tea, and coffee ensures quality, shelf life, and compliance to food safety standards.
Agriculture
Drying rates of seeds, feeds,and fertilizers determine compliance with USDA standards and support accurate pricing and storage planning.
Paper & Pulp
Control paper moisture for accurate grammage in line with ISO 12086 and ISO 21732 requirements:-ensuring consistent production quality.
Pharmaceuticals & Labs
Validate moisture in APIs and excipients to meet USP, EP, and ASTM moisture content standards, essential for stability and efficacy.
The moisture content of the sample is determined by the thermogravimetric method. It is composed of weighing units and heating units. It is widely used in industrial, agriculture, and laboratory applications. Some typical applications are tobacco, paper, food, tea, chemical, row materials, etc.
Technical Specifications of the Best Halogen Moisture Analyzer
| Model | TT-HMCA | ||
| Range | 120g | ||
| Readability | 0.001g | ||
| Display | 5” touch screen | ||
| SUS 304 Pan size | Φ90 | ||
| Temperature range | 40℃ to 200℃ by 1 ℃ step | ||
| Moisture range | 0.04% to 100% | ||
| Moisture readability | 0.01% | ||
| Time setting | 1 to 99min | ||
| Number of storage | 100 | ||
| Heating source | Halogen light (annular 450W) | ||
| Display results | test temperature, test time, moisture content, solid content, weight after drying, dynamic curve, moisture regain, solid content, weight loss, dry weight, test method, sample name, maximum value, minimum value, average value | ||
| User management: | Password protection, multiple users, automatic locking | ||
| Stop mode: | automatic stop, manual stop, timed stop | ||
| Communication: | RS232 port, may connect to printer and computer | ||
| Power supply: | 220V 50HZ 450W | ||
Testron’s Halogen moisture analyzer reduces both time and energy consumption compared to conventional ovens, making it the green choice for labs. Precision heating ensures efficient resource use and reduced energy consumption:-contributing to a sustainable lab infrastructure.
Calibration services and traceable certificates are available at purchase, with re calibration recommended annually. The durable halogen lamp, stainless components, and easy maintenance make the TT‑HMCA a reliable long term investment.
High speed Halogen Heating
The core of our moisture analyser is a 500 W halogen lamp, which delivers instant, uniform heating far more efficient than traditional ovens. This feature reduces test time and energy use, significantly lowering the halogen moisture analyzer price by reducing operational costs.
Precision Weighing & Temperature Control
Using imported German HBM load cells ensures accurate weighing with minimal drift. A PT100 sensor monitors temperature in real time, maintaining accuracy during moisture extraction and providing consistent results.
Intuitive Touch Control & Voice Prompts
The 5” color touchscreen, adorned with guided, icon driven prompts and voice instructions, makes operation simple. Users can customize voice feedback or disable it:-providing both accessibility and user comfort.
Built in Database & Data Export
Store up to 2,000 records with timestamped data. USB enabled exports and real time USB tracking give you robust data management capabilities, perfect for remote labs and high throughput environments
RS232 & USB Connectivity
Seamlessly link the moisture tester to printers, PCs, or LIMS systems. Optional RS232 output supports labels and reports:-helpful for compliance driven labs.
Compact Yet Rugged Build
The stainless steel heating chamber and halogen protection offer durability and hygienic performance. The splash proof and explosion proof design ensures safe operation in demanding environments.
Frequently Asked Questions About Halogen Moisture Analyzer
The TT‑HMCA halogen moisture tester heats samples faster and with more uniformity, significantly reducing testing times and energy use compared to traditional oven methods.
Annual halogen moisture analyzer calibration is advised for accurate results. We also offer onsite calibration services across the USA.
Yes. With a 0.001 g readability and a moisture range up to 100%, the device accurately measures all sample moisture contents.
Prices depend on configurations and accessories. Contact us for a transparent halogen moisture analyzer price and value added packages.
Yes. The interactive touchscreen and voice guidance make it easy to operate even for non technical staff. USB/RS232 outputs support integration into production data systems.
Yes, data can be saved to USB in CSV format or printed via RS232:-supporting quality systems and audit trails.
Contact us Today
Ready to Optimize Moisture Testing?
Inquire Now to receive a quote, halogen moisture analyzer price, calibration details, and integration support:-backed by Testron’s USA based service team.
