Coefficient of Friction Tester Standards:
ASTM D1894 -01, ISO 8295, TAPPI 816, GB 10006-88
Coefficient of Friction Tester Features:
- Can test independently without a computer.
- LCD display dynamic COF and static COF.
- Simple calibration of a force sensor.
- Professional software, simple interface, easy to use.
- Display multiple curves; can zoom curve.
- Professional test report.
Coefficient of Friction Tester Specifications:
| Item | Technical Parameters |
| COF test range | 0.01~0.999 |
| Precision | ±0.01 |
| Force range | 0~10N |
| Sliding speed | 100±10mm/minute |
| Slider size | 63mm × 63mm |
| Slider weight | 200±2g |
| Sliding platform size | 200×470mm |
| Sample thickness | ≤2mm |
| Weight | 23kg |
| Instrument size | 470 mm × 340mm × 220mm |
| Power | 100W |
| Power supply | AC220V 50Hz |
Coefficient of Friction Tester Configuration List:
| A, Spare parts | ||||
| NO. | Name | Remark | Quantity | |
| 1 | Power cable | 3*0.75 10A 1.8M | 1 PC | |
| 2 | Allen wrench | 1 PC | ||
| 3 | Cross screwdriver | 6-10mm | 1 PC | |
| 4 | Wooden box | 1 PC | ||
| 5 | Slider | 200g | 1 PC | |
| 6 | Weight | 200g | 1 PC | |
| B, Optional parts | ||||
| NO. | Name | Unit | Quantity | Remark |
| 1 | Computer | Set | 1 | Optional |
| 2 | Metrology Certificates | Optional | ||
| C, User provide | ||||
| 1 | Power supply 500w 220V 10A 3 holes socket ground wire | |||
| 2 | 1 set of computers (with nine-pin COM port），system/Windows7 | |||
