Noxious gas tеst chambеrs play a crucial role in thе industrial sector by еnsuring thе longеvity and rеliability of various matеrials and componеnts. Thеsе chambers simulate thе corrosive effects of gasses such as SO2 (Sulfur Dioxidе), H2S (Hydrogеn Sulfidе), CO2 (Carbon Dioxidе), and HCl (Hydrochloric Acid) undеr controllеd conditions of tеmpеraturе and humidity. According to industry standards such as IEC 60068-2-42 and IEC 60068-2-60, thеsе tests are essential for evaluating material rеsiliеncе and predicting sеrvicе life. Lеading manufacturеrs offеr both singlе gas and mixеd gas tеst options, making thеsе chambers indispensable for industriеs ranging from еlеctronics to construction.
Noxious Gas Test Chambers | Overview
Noxious gas test chambers are specialized enclosures designed to simulate the corrosive effects of various gasses, such as SO2, H2S, CO2, and HCl, on materials, components, and constructions. These chambers are used to evaluate the resistance of products to corrosion, ensuring their safety and integrity in environments where noxious gasses are present.
To evaluate the resistance of products to degradation caused by exposure to toxic and corrosive gasses, there are a range of Noxious Gas Test Chambers such as:
- Noxious Gas Test Chambers for SO2 (sulfur dioxide)
- Noxious Gas Test Chambers for H2S (hydrogen sulfide)
- Noxious Gas Test Chambers for CO2 (carbon dioxide)
- Noxious Gas Test Chambers for HCl (hydrochloric acid)
Test Standards
Several international and industry-specific standards guide the design and operation of noxious gas test chambers. Notable standards include:
- IEC 60068-2-60: Flowing mixed gas corrosion test
- PN-EN 60512-11-14: Climatic tests – test 11p: flowing single gas corrosion test
- ASTM B845-97: Mixed flowing gas tests for electrical contacts
- Renault 36-00-802 and VW 80000: Corporate standards for electric and electronic components in motor vehicles
Chamber Types
Noxious gas test chambers come in various sizes and configurations, including:
- Reach-in chambers for testing small samples
- Walk-in chambers for testing larger samples or equipment
- Drive-in chambers for testing vehicles or machinery
- Custom chambers designed for specific testing requirements
Key Features:
- Various models are available, including SO-100, SO-225, SO-500, SO-800, and SO-1000, with internal dimensions ranging from 450x450x500 mm to 1000x1000x1000 mm and overall dimensions up to 2315 mm in height.
- Temperature range: 15°C to +80°C.
- SO2 concentration: 25 ±5 ppm.
- Nichrome heaters for temperature control and humidity control.
- Test methods comply with IEC 60068-2-42, IEC60068-2-60, and other standards.
Industrial Applications:
- Material Testing
- Assess corrosion damage to materials when exposed to SO2, H2S, CO2, and HCL gasses.
- Evaluate the durability and integrity of different materials under corrosive conditions.
- Component Testing
- Test electronic contacts and connections for corrosion resistance.
- Verify the long-term functionality of critical components in harsh environments.
- Construction Testing
- Examine the effect of corrosive gasses on construction materials, ensuring they can withstand noxious gas exposure.
- Ensure that construction materials meet safety and durability standards.
- Standards Compliance
- Conduct tests in accordance with international standards such as IEC 60068-2-42 and IEC 60068-2-60.
- Ensure compliance with industry-specific regulations and requirements.
- Product Development
- Validate new products and materials designed to resist corrosion from SO2, H2S, CO2, and HCL gasses.
- Enhance the reliability and safety of products before market launch by simulating real-world corrosive conditions.
- Quality Control
- Perform routine quality checks on materials and components to ensure consistent performance.
- Identify potential weaknesses and ensure high standards of manufacturing quality.
- Research and Development
- Support R&D efforts by providing accurate data on the effects of noxious gasses on various materials and components.
- Facilitate the development of new corrosion-resistant technologies and materials.
Noxious Gas Test Chambers – Testing Procedure
- Preparation
- Ensure the test chamber is cleaned and free of contaminants.
- Verify the airtight integrity of the chamber to prevent gas leakage.
- Set up the test specimen inside the chamber according to the specific test protocol.
- Gas Introduction
- Introduce the noxious gas (SO2, H2S, NO2, etc.) into the chamber at the specified concentration.
- Monitor gas concentration to ensure it remains within the target range.
- Temperature and Humidity Control
- Adjust the chamber temperature to the required test conditions, typically between 20°C to 30°C.
- Control the relative humidity within the chamber, maintaining it at specified levels, usually 75% to 90%.
- Test Duration
- Conduct the exposure test for the prescribed duration, which can vary from several hours to multiple weeks, depending on the material and test standards.
- Monitoring During Test
- Continuously monitor the gas concentration, temperature, and humidity to ensure consistent test conditions.
- Record data at regular intervals for analysis and validation.
- Post-Test Procedures
- Upon completion of the test, safely vent the noxious gas from the chamber.
- Remove the test specimen and perform any required post-test evaluations, such as visual inspections or structural assessments.
- Documentation
- Document all test conditions, procedures, and observations in a detailed report.
- Compare test results with the standard references to determine the performance and durability of the test specimen.
